0.75 ltr 210 bar Diaphragm Accumulator Hydraulic Accumulator Gas Cylinder
| Model: | GXQ |
| Place of Origin: | Zhejiang,China (Mainland) |
| Brand Name: | Drift |
| Volume: | 0.75 ltr |
| Working Pressure: | 210 bar |
Product Description
| Payment & Shipping Terms | Supply Capacity | ||
|---|---|---|---|
| Unit Price: | 70.0~100.0 USD | Production Capacity: | 10000PCS PER MONTH |
| Trade Term: | FOB | Packing: | WOODEN BOX OR PAPER... |
| Payment Terms: | T/T | Delivery Date: | 35 WORKING DAYS AFTER... |
| Min. Order: | 100 Piece/Pieces | ||
| Means of Transport: | Ocean, Air, Land | ||
------------------------------------------------------------
DIAPHRAGM ACCUMULATOR DIMENSION DRAWING
MODEL: GXQ-*-0.75/*-L(F)-*
WORKING PRESSURE: 210 BAR
CAPACITY: 0.75 LTR
d1: M22x1.5
d2: M28x1.5
L: 190
D: 126
WORKING PRESSURE: 210 BAR
CAPACITY: 0.75 LTR
d1: M22x1.5
d2: M28x1.5
L: 190
D: 126
Nom.Volume | Work Pressure | Size(mm)Dimension | |||||
Fluid port d1 | Inlet port d2 | D | L | ||||
Metric standard | ISO228 | Tailor made | |||||
0.07 | 210-330 | M14×1.5 | G1/2 | Pls contact | M28×1.5 | φ65 | 120 |
0.25 | 210-330 | M16×1.5 | M28×1.5 | φ95 | 145 | ||
0.35 | 210-330 | M18×1.5 | M28×1.5 | φ100 | 167 | ||
0.75 | 210-330 | M22×1.5 | M28×1.5 | φ126 | 190 | ||
